Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient

Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient
Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient

Large Image :  Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient

Product Details:
Place of Origin: CHINA
Brand Name: Altrasonic
Certification: CE
Model Number: HS-C30
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: Negotiation
Packaging Details: Carton packing
Delivery Time: 7 workdays afer receiving the payment
Payment Terms: T/T, Western Union
Supply Ability: 1000 pieces per month

Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient

Description
Frequency: 30Khz Power: 200W
Blade: Replaceable Material Of The Blade: Titanium
Application: Cutting, Deburring Of Molded Parts Generator: Digital
Certificate: CE Aftersales Service: Online Service
High Light:

Ultrasonic Cutting Machine 30kHz

,

Titanium Blade Ultrasonic Cutting Machine

,

High Efficient Ultrasonic Cutting Machine

High Efficient 30kHz Ultrasonic Cutting Machine With Digital Generator For Metal And Plastic Cutting



30kHz Ultrasonic Cutting Machine with Digital Generator for Metal and Plastic Cutting



Specification:



Model HS-C30
Frequency 30KHZ
Output Power 200W
Generator Digital generator, 452 x 180 x 100mm
Handle Φ44×220
Size of cutter Blade replaceable
Length of cable 3M
Outer skin Aluminum
Weight 8KG
Voltage 220V / 110V
Accessory Foot switch 1pc;Cut blade 2pcs;
1.5mm special hex wrench 1pc;Screw M3×4L 2pcs
Material of blade titanium alloy, stainless steel





Description:



Ultrasonic cutting principle is through the ultrasonic generator to 50 / 60Hz current into 20,30 or 40kHz power. The converted high frequency electric energy is again converted into mechanical vibrations at the same frequency by the transducer, and then the mechanical vibration is transmitted to the cutter by means of a set of amplitude modulator devices which can change the amplitude. The cutting tool transmits the received vibration energy to the cutting surface of the workpiece to be cut in which the vibration energy is cut by means of activating the molecular energy of the material to be cut and opening the molecular chain.



Easy to take! Easy to operate! Easy to install!



Application:

  • Natural fibers
  • Synthetic fiber
  • Thin plastic products(Such as plastic film, cell phone case)
  • All types of paper, bottom film
  • Rubber, silicone
  • Repair of printed circuit board copper foil
  • ABS,PP,PE … other organic plastic sheet less than 2mm
  • Various types of synthetic fabrics
  • 30K ultrasonic cutting knife can be used for hand-held cutting and automatic mechanical clamping.



Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient 0Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient 1Digital Generator Ultrasonic Cutting Machine 30kHz For Metal Plastic High Efficient 2
