Product Details:
|
| Frequency Range: | 1KHz~1MHz | Measurement Index: | All The Parameters, The Graph |
|---|---|---|---|
| Measurement Accuracy: | < 0.5% | Measurement Speed: | 5s/one Pass （600scan Point） |
| Phase Resolution: | 0.15 Degree | Frequency Step: | 0.1Hz～any |
| Power Supply: | AC100V～AC250V，50～60Hz, 30W | Application: | Ultrasonic Device |
| High Light: | measurement instruments,analyzer instrument |
||
Frequency Analyzing Implement
Description:
Ultrasonic impedance analyzers are characterized by ease of use, combination of indicators and graphics, and accurate parameters.Ultrasonic impedance analyzer series products are suitable for measuring various ultrasonic equipment, including: piezoelectric ceramics, sensors, ultrasonic cleaning machines, ultrasonic plastic welding machines, underwater acoustics, magnetostrictive materials, ultrasonic grinding machines, ultrasonic atomizing, ultrasonic Cleaning, reversing radar, ultrasonic ranging, phacoemulsification, ultrasonic cleaning, ultrasonic motors, and all other equipment and devices used in piezoelectric and ultrasonic applications.
Specification:
Model: HS-520F
Frequency Range: 10K-100K
Environment Temperature: Normal
Display: 3.2 Inch TFT(320*240)
Power Supply: Two 3.7V Rechargeable Lithium Batteries
Operation Style: Film Button
Size (mm): 216(L)*100(W)*34(D)
Weight (g): 354
Input Power: 4.2-40(Vpp)
Application:
It is a test of the instrument's wireless remote control frequency, which can accurately test the frequency of the ultrasonic device and clearly display the real-time frequency. Its effective test range is 10-100khz. The test method is very simple, as long as you need to test the tip of the ultrasonic device near the frequency meter to accurately test the frequency of the device. The device accurately measures the frequency of the ultrasonic transducer for easy portability.
