8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer

China 8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer supplier
8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer supplier 8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer supplier 8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer supplier 8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer supplier

Large Image :  8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer

Product Details:

Place of Origin: CHINA
Brand Name: Altrasonic
Certification: CE
Model Number: HSD70S

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: Wooden case
Delivery Time: 7 working days
Payment Terms: T/T, Western Union
Supply Ability: 5000 Set per month
Contact Now
Detailed Product Description
Frequency: 70khz Power: 300w
Power Adjusting Method: Step Or Continuous Switch: Handle,foot Switch.or Linked Outside
Working Time Control: 0-999seconds Generator: Digital Generator
Net Weight: 10kgs The Threading Hole: Ø0.5m Or Design According To Customers' Need
Cooling Down Method: Compressed Air Outer Housing: Aluminium Or Nylon

Simultaneously Embedding the Copper Antenna onto PVC Layer by the Ultrasonic 8 Heads



Description:



Radio frequency identification (RFID) inlays are manufactured throughout the world for many purposes: biometric passports, the contactless smart card market (e-ID, electronic healthcare cards, payment cards, public transportation), and for dual interface applications. At the same time, wire-embedded high frequency (HF) RFID antennas are available and offer a number of advantages over printed, etched, or galvanized variations.



Parameters:



Frequency 70khz
Power 500w
Power Adjusting Step or continuous
Switch Handle , foot switch,or linked outside
Working Time control 0-999seconds
Generator Digital generator
Cable 2M, national standard
The threading hole Ø0.5m or design according to customers' need
Cooling down method Compressed air
Outer housing aluminium or nylon



Components and Parts

Generator

Booster

Converter

Welding Horn

Protective Sleeve (Nylon and Aluminum optional)

HF Cable

Power Cable



Development and functional characteristics of ultrasonic Embedding line machine



The application and popularization of ultrasonic embedding wire machine in the smart card industry have been more than 20 years of history. Due to being loved and favored by many manufacturers, it has been rapidly developed and improved since it was put into operation. From the beginning of the single head winding, to the current 4/5 head / 8 simultaneous winding; from the previous single-processing platen operation to the current two sets of processing platen automatic cycle switching, winding speed from the previous 100 coils / hour to the current 2000 coil / hour or more.

The existing ultrasonic embedding wire embossing machine basically adopts a professional motion controller with a high-speed CPU to ensure the high-speed response of complicated mechanical actions and complete complex multi-axis motion control so as to realize the precision embedding of complex products. The vacuum suction plate Absorbing material embedding, effectively ensure the accuracy of the antenna embedding a smooth; embedding thread buried by ultrasonic technology, the entire process of program control fully automatic operation, easy operation, stable and reliable operation; using two automatic cycle switching workbench Plate, refueling without downtime, high production efficiency; each group of buried wire antenna group are independent units, both at the same time, you can also choose one of the groups at the same time work, high flexibility. Winding process than the traditional winding machine to be fast, save manpower, and more stable performance.



What Is an RFID Inlay?



Radio-frequency identification, or RFID, technology provides identifying information about a person or an object, much like barcode technology does. The RFID inlay -- which can be as small as a grain of rice -- is the functional part of an RFID tag's label that encodes the identifying information. The RFID inlay uses radio frequency waves to relay information to a computer system via an RFID reader.

Components

The RFID inlay consists of two components. An integrated circuit or microchip that stores personal identifying information attaches to a small coil of aluminum, copper or silver wires called the antenna, which transmits and receives radio frequency signals. The microchip and antenna are then placed on a label, and the entire unit is encased in plastic.

How It Works

Data from the microchip passes to the RFID tag's antenna, where it is read by the antenna of an RFID reader and passed onto a host computer system for archival purposes, processing or analysis.

Types

RFID inlays are classified as "wet" or "dry." RFID inlays are considered "wet" if an adhesive is applied to the inlay to adhere it to a pressure-sensitive liner that comprises the label. Inlays are considered "dry" when the inlay is attached to the label without the use of an adhesive.



Simultaneously Embedding the Copper Antenna onto PVC Layer by the Ultrasonic 8 Heads



8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer



8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer



8 Heads Ultrasonic Plastic Welding Machine Simultaneously Embedding Copper Antenna onto PVC Layer
