High Precision 15khz Ultrasonic Plastic Welding Machine Automatic HSW15B

China High Precision 15khz Ultrasonic Plastic Welding Machine Automatic HSW15B supplier

Large Image :  High Precision 15khz Ultrasonic Plastic Welding Machine Automatic HSW15B

Product Details:

Place of Origin: CHINA
Brand Name: Altrasonic
Certification: CE
Model Number: HSW15B

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 7 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 300 units per month
Contact Now
Detailed Product Description
Product Name: Ultrasonic Plastic Welding Machine Frequency: 15k
Power: 2000w Max Current:: 10A
Origin: CHINA Model: HSW15B







High precision20khz Automatic ultrasonic welding machine

Description:

This BRAND NEW type of Ultrasonic Welding Machine was reserched and developed for more than 2 years by our company. it adopts high performance tamper-proof microprocessor, realizing the electronic control, welding manage all control parameters by microcomputer, frequency control system, intelligent discharge the inconvenience of manual FM, sonic overload automatic detection, when the real track best resonance point, vibration group keep in low temperature, welding head temperature increase while the frequency will change accordingly, the machine automatically adjustment make it running more stable.







Applications:
Toy industry: Such as toy gun, water gun, telephone and rag baby etc.
Electronic industry: The gum case of watch, nylon watch band, calculator, sound box wraps hull, cell phone battery etc.

Automotive industry: Car light, automotive interior parts etc.

Packing industry: Disguise box, PVC packing box, toothpaste tube etc.

General business ware: The inkjet cartridge, video cassette rack, tape box, computer disk etc.

Medical industry: Widely used in the medical industry due to the fast,clean,efficient of ultrasonic welding machine.







Specifications:


Item No HS-X20P HS-X15P
Frequency 20Khz 15Khz
Power 1500W 3300W
Voltage 200-240V, Alternating current 200-240V,Alternating current
50-60hz, Single phase 50-60hz, Single phase
Electric current 10A 20A
Range of welding time 0.05-10/sec 0.05-10/sec
Environment Temperature 5-50℃ 5-50℃
Air supply requirements Clean dry compressed air, maximum pressure 7kg Clean dry compressed air, maximum pressure 7kg
Maximum pressure 1.96KN 2.89KN
Maximum stroke 100MM 100MM
Beats 80/Min 50/Min
Triggered Dynamic range 67-890N 135-990N
Weight 66Kgs 68Kgs
Dimension 476mm(L)*736mm(W)*1524mm(H) 476mm(L)*736mm(W)*1524mm(H)








Detailed Images:


High Precision 15khz Ultrasonic Plastic Welding Machine Automatic HSW15B

High Precision 15khz Ultrasonic Plastic Welding Machine Automatic HSW15BHigh Precision 15khz Ultrasonic Plastic Welding Machine Automatic HSW15B
