Auto Tuning Capabilities Ultrasonic Homogenizer Equipment

Auto Tuning Capabilities Ultrasonic Homogenizer Equipment
Auto Tuning Capabilities Ultrasonic Homogenizer Equipment Auto Tuning Capabilities Ultrasonic Homogenizer Equipment

Large Image :  Auto Tuning Capabilities Ultrasonic Homogenizer Equipment

Product Details:
Place of Origin: CHINA
Brand Name: Altraasonic
Certification: CE
Model Number: HSS15B-EB
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: Packed in carton, and PE form inside
Delivery Time: 10 working days after received your payment
Payment Terms: T/T
Supply Ability: 100pcs per month

Auto Tuning Capabilities Ultrasonic Homogenizer Equipment

Description
Name: Ultrasonic Homogenizer Frequency: 20Khz
Power: 2000W Weight: 13Kg
High Light:

ultrasonic dispersion equipment

,

ultrasonic biodiesel reactor

Auto Tuning Capabilities Ultrasonic Homogenizer Equipment With Glass Container



Specifications:



Model

S20-1000

S20-1500

S20-2000

S20-3000

Frequency

20±1 KHz

20±1 KHz

20±1 KHz

20±1 KHz

Power

1000 W

1500 W

2000 W

3000 W

Voltage

220±10% V

220±10% V

220±10% V

220±10% V

Temperature

300 ℃

300 ℃

300 ℃

300 ℃

Pressure

35 MPa

35 MPa

35 MPa

35 MPa

Intensity of sound

>20 W/cm²

>30 W/cm²

>40 W/cm²

>60 W/cm²

Max Capacity

> 10 L/Min

> 15 L/Min

> 20 L/Min

> 30 L/Min

Material Of Tip Head

Titanium Alloy

Titanium Alloy

Titanium Alloy

Titanium Alloy





Applications
Prepare Tissue Prepare Emulsions Immiscible Liquids
Accelerate Enzymatic Reactions Accelerate Chemical Reactions Stimulate Bacterial Activity
Disperse Solids De-gas Liquids Deaglomerate Powders
Dissolve Powders Dissolve Tablets Emulsify Cosmetics
Extract DNA / RNA Extract Proteins Emulsify Liposomes



Ultrasonic Homogenizer

Sometimes referred to as Sonicator, Cell Disrupter or Cell Disruptor, Sonifier, Probe Sonicator, Ultrasonic Liquid Processor, and Sonic Dismembrator.



How it Works



The ultrasonic power supply transforms line voltage to high frequency 20 kHz electrical energy. This electrical energy is transmitted to the probe where it is converted to mechanical energy. The vibrations from the probe are coupled to and intensified by the titanium tip. The probe vibrates in a longitudinal direction and transmits this motion to the titanium tip immersed in the solution. Cavitation results, in which microscopic vapor bubbles are formed momentarily and implode, causing powerful infinitesimal shock waves to radiate throughout the solution in proximity to the radiating face of the tip.



Automatic Tuning



All the of our Ultrasonic Homogenizers models employ a propriety feedback system, insuring that the generator is always working at it maximum efficiency regardless of the application. There is no need for constant adjustment by the operator. The percentage of ultrasonic power emitted is indicated by the output LED meter, enabling accurate reproducible results.



Competitive Advantage:

  • Custom System Designs and Consulting.
  • Active Ultrasonics provides consulting services and custom reactor designs.

  • High amplitude probe flow cells.

  • Unrestricted flow-through cylindrical systems.

  • High Power Probe Sonicator.



Custom sizes available for laboratory and high volume industrial applications.





Auto Tuning Capabilities Ultrasonic Homogenizer Equipment 0



Auto Tuning Capabilities Ultrasonic Homogenizer Equipment 1
