High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments

High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments
High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments

Large Image :  High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Certification: BV
Model Number: HS-AG15
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Packaging Details: carton
Delivery Time: 7 workdays after payments
Payment Terms: T/T, Paypal
Supply Ability: 1000 units per year

High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments

Description
Prduct Name: 30KHz Ultrasonic Atomizer Machine Frequency: 30
Atomizing Volume: 150L/H Dia. Average Particle: 62um
Power: 500W
High Light:

500 Watts Ultrasonic Nebulizer

,

High Power Ultrasonic Nebulizer Equipments

,

500W Ultrasonic Nebulizer machine

High Power 500Watts Ultrasonic Spray Coating System Nebulizer Equipments





Description:


Ultrasonic spray (FOG) is to use the energy of ultrasonic water or liquid scattered, forming several microns to 100 microns in size of particles, used for air humidifying, granulating, mixing liquid, promote chemical reactions, spraying, molten metal powder etc.By breaking apart aggloomerated particles as they travel down the nozzle body due to continuous ultrasonic vibrations along the length of nozzle, resulting in the most effective use of functional particles.





Technical Parameters:



Frequency: 15KHz

Power: 500W

Major power supply: 220V 50HZ 2A

Power Consumption: 0.001 Degrees/Kg

Atomization Volume: 150L/H

Average Particle Diameter Of Fog: 62um

The Application of Atomizing Media: Ordinary water, a variety of liquid substances, chemical liquid, a variety of oil mucus, metal melt and so on.





Applications:



Atomization humidification, chemical mixing, production, spray drying granulation, paint spraying, metal milling and so on. The advantage is that it can atomize various kinds of liquid and it has Large atomizing volume, energy-saving, environmental protection. It has no plug, no abrasion.





Specifications:



Model HS-N60 HS-N50A HS-N50B HS-N50C HS-N40 HS-N30 HS-N20 HS-N15
Frequency 60KHz 50KHz 50KHz 50KHz 40KHz 30KHz 20 KHz 15 KHz
Atomization Volume 0.5L/H 2 L/H 2 L/H 2 L/H 10 L/H 50 L/H 100 L/H 150 L/H
Average Particle Diameter of Fog 20um 28um 28um 28um 32um 39um 51um 62um
Power Consumption 0.01 Degrees/Kg 0.001 Degrees/Kg
Atomization Head Structure Cylindrical Horn
Power 30W 30 W 30 W 30 W 60 W 100 W 300 W 500 W
The Application of Atomizing Media

Ordinary water, a variety of liquid substances, chemical liquid,

a variety of oil mucus, metal melt and so on





Ultrasonic nozzle benefits:



Spray patterns are easily shaped for precise coating applications
Highly controllable spray produces reliable, consistent results
Corrosion-resistant titanium and stainless steel construction
Ultra-low flow rate capabilities, intermittent or continuous
No moving parts to wear out
Non-clogging
Drops sizes as small as 13 microns, depending upon nozzle frequency
reduce downtime in critical manufacturing processes





Competitive Advantages:



★ A major breakthrough in spray technology, you can spray a variety of liquids.
★ Low power consumption, the fog of great energy saving.
★ No plug, no abrasion, no noise, no pressure, no moving parts.
★ Can be any combination to meet the requirements of the spray volume.
★ The use of high-performance titanium and stainless steel.



High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments 0

High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments 1

High Power 500 Watts Ultrasonic Spray Coating System Nebulizer Equipments 2
