Product Details:
|
| Product Name: | High Pressure Atomizer Ultrasonic Nozzle Spray For Chemical Mixing 150 L/H 62μm | Frequency: | 15Khz |
|---|---|---|---|
| Atomization Volume: | 150L/H | Average Particle Diameter Of Fog: | 62um |
| Power: | 500W | Atomization Head Structure: | Horn |
| Origin: | China | Material: | Plastic Or Stainless Steel |
| High Light: | 15kHz Ultrasonic Atomized Machine,Diameter 62mm Ultrasonic Atomized Machine |
||
15kHz Hot Sale Good Effect Ultrasonic Atomizer Atomized Machine Particle Diameter 62mm
Specifications:
|
Model |
HS-N60 |
HS-N50A |
HS-N50B |
HS-N50C |
HS-N40 |
HS-N30 |
HS-N20 |
HS-N15 |
|
Frequency |
60KHz |
50KHz |
50KHz |
50KHz |
40KHz |
30KHz |
20 KHz |
15 KHz |
|
Atomization Volume |
0.5L/H |
2 L/H |
2 L/H |
2 L/H |
10 L/H |
70 L/H |
100 L/H |
150 L/H |
|
Average Particle Diameter of Fog |
20um |
28um |
28um |
28um |
32um |
39um |
51um |
62um |
|
Power Consumption |
0.01 Degrees/Kg |
0.001 Degrees/Kg |
||||||
|
Atomization Head Structure |
Cylindrical |
Horn |
||||||
|
Power |
30W |
30 W |
30 W |
30 W |
60 W |
100 W |
300 W |
500 W |
|
The Application of Atomizing Media |
Ordinary water, a variety of liquid substances, chemical liquid, a variety of oil mucus, metal melt and so on |
|||||||
Description:
The ultrasonic atomization equipment unit is composed of a dedicated drive power supply, atomization head, horn, and ultrasonic transducer. The special drive power supply is connected to the transducer to drive the atomizing head to vibrate at high frequency to produce atomization. It is characterized by high power, the maximum atomization volume of one unit can exceed 100L/h, the atomization effect is high, the ultrasonic frequency is low, and a variety of liquid media can be used, even sewage, chemical liquids, and oil mucus can be atomized. No pressure, no noise, no nozzle wear and clogging problems, low energy consumption, small size of a single machine, and the amount of atomization can be adjusted at will, which is very suitable for production requirements in the industrial field.
Applications:
The ultrasonic atomizer adopts a high-efficiency integrated circuit, a unique structure design of ultra-small integration, and high-quality atomizing tablets are used for important parts.
Wide range of uses for humidifiers, incense burners, beauty machines, disinfection machines, bathtub fog machines, bonsai, and handicrafts.
Competitive Advantage:
1. Reduce material consumption and overspray by up to 80%
2. Highly controllable spray pattern for reliable, consistent results
3. Corrosion Resistant Construction
4. Ultra low flow capability
5. Low maintenance anti-clogging design
6. Reduce downtime in critical manufacturing processes
7. High reliability with no moving parts
8. Controlling atomized droplet size by selecting nozzle frequency
9. Tight droplet distribution optimizes desired coating morphology
10. Manufactured from high-performance titanium and stainless steel.
Picture:
