10m/Min Aluminum Ultrasonic Plastic Welding Machine For Plastic Pipe

10m/Min Aluminum Ultrasonic Plastic Welding Machine For Plastic Pipe
10m/Min Aluminum Ultrasonic Plastic Welding Machine For Plastic Pipe

Large Image :  10m/Min Aluminum Ultrasonic Plastic Welding Machine For Plastic Pipe

Product Details:
Place of Origin: CHINA
Brand Name: Altrasonic
Certification: CE
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 10 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 200 Set per month

10m/Min Aluminum Ultrasonic Plastic Welding Machine For Plastic Pipe

Description
Frequency: 20kHz Power: 2000w
Welding Rate: 4-10m/min (According To The Thickness Of The Material) Welding Thickness Of Beaten Aluminum: 0.2-0.5mm (According To The Quality Of The Material)
Diameter Of Horn: Dia 51mm Operating Mode: Automatic, Manual Test
High Light:

Alu Ultrasonic Plastic Welding Machine

,

20kHz Ultrasonic Plastic Welding Machine

,

10m/min Ultrasonic Plastic Welding Machine

Ultrasonic aluminum-plastic pipe welding machine for plastic pipe welding



Description:



The tail of the hose is welded by ultrasonic, and the welding strength is equal to that of the plastic itself. It can automatically drop the pipe for labeling, welding, tail trimming, and serial number; using PLC control, simple operation.



Specification:

1. Operating Frequency : 20 ±1KHz;

2. Maximum Ultrasonic Output Power: 2000w

3. Welding Rate: 4-10m/min (According To the Thickness Of The Material)

4. Welding Thickness of Beaten Aluminum: 0.2-0.5mm (According to the Quality Of The Material)

5. Diameter of Horn: Dia 51mm

6. Operating Mode: Automatic, Manual Test

7. Operating Pneumatic Pressure : 0.2-0.6Mpa

8. Power: AC220V±5% ,50Hz±1%

9. Dimensions:

Generator : 450×600×160mm3

Stand: 400×330×220 mm3

10. Operating Ambient Temperature: 0-50℃

11. Motor: Three Phase AC 220V Conversion Motor (51KGV20)



10m/Min Aluminum Ultrasonic Plastic Welding Machine For Plastic Pipe 010m/Min Aluminum Ultrasonic Plastic Welding Machine For Plastic Pipe 110m/Min Aluminum Ultrasonic Plastic Welding Machine For Plastic Pipe 2
