Dunkane 110-3168 Utrasonic Welding Converter With 2 Nos Peizo 45mm Diameter

China Dunkane 110-3168 Utrasonic Welding Converter With 2 Nos Peizo 45mm Diameter supplier
Dunkane 110-3168 Utrasonic Welding Converter With 2 Nos Peizo 45mm Diameter supplier Dunkane 110-3168 Utrasonic Welding Converter With 2 Nos Peizo 45mm Diameter supplier Dunkane 110-3168 Utrasonic Welding Converter With 2 Nos Peizo 45mm Diameter supplier

Large Image :  Dunkane 110-3168 Utrasonic Welding Converter With 2 Nos Peizo 45mm Diameter

Product Details:

Place of Origin: CHINA
Brand Name: Altrasonic
Certification: CE
Model Number: HSD-110-3168

Payment & Shipping Terms:

Minimum Order Quantity: 2 units
Price: Negotiation
Packaging Details: Packed in carton
Delivery Time: 7 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 3000 units per month
Contact Now
Detailed Product Description
Product Name: Ultrasonic Converter Frequency: 20Khz
Power: 800w Ceramic Diameter: 45mm
Joint Bolt: 1/2-20UNF Ceramic Disc: 2 PCS
Material: Titanium, Aluminum Materials Optional Color Of The Ceramic: Yellow

Dunkane 110-3168 Utrasonic Welding Converter with 2 nos Peizo 45mm Diameter

Specifications:



ModelHS-110-3168
Frequency20 khz
Output power800 watt
Joint bolt1/2-20UNF
Ceramic disc Diameter45 mm
Quantity of Ceramic discs2 pcs
BoltFixing with transducer body
Amplitude12um
Applicationwelding machine



Description:

The Replacement Converter for Dukane 20khz machine Direct replacement for the Dukane 20khz machine that delivers lower cost, rugged quality and superior value.
Ultrasonic transducer works by converting electrical energy into mechanical energy through the performance of piezoelectric ceramic. Our transducers are made of Imported ceramic discs and superior aluminum raw materials. We can replace the front and back cover of the transducer according to the need. T
he Replacement Converter for Dukane 20khz machine is used in the welding machine, can be used to weld like metal, thermoplastic and other materials.So it has good heat resistance, and adapt to a large range of working temperature.
Warranty:

We offer the same warranty as the OEM, namely, three years one-time replacement.
Simply ship the broken unit back to arrive within three years of original shipment, and it will be replaced
(one time).



Applied Range:

Automotiveengine, compartment, functional, components, exterior/light, interior
Electronicsensors, switches, housings, electrical devices, cable and quick disconnect systems
Medicalmembranes, adaptors, connectors, fluid containers, filters, breathing masks, wound dressing, bandaging material
Consumerhousehold, leisure, garden, toys, office, packaging
Automationindustrial, automation, multihead components, flexibte robot cells


Competitive Advantage:

  1. Titanium materials and Aluminum materials optional.
  2. Once assembled, the transducers are aged before testing and final assembly. The properties of piezoelectric materials can change with time and pressure, so a bit of time on the shelf prior to testing will identify nonconforming material.
  3. One by one testing to ensure that each transducer performance are excellent.
  4. In good heat resistance, can be used in a wide range of temperature with long life and high reliability.
What we can do for you:
  • OEM - special custom-made the ultrasonic transducers or parts for you, and save cost for you.
  • Supply Replacement converter - Including NTK, Branson CJ20, CR20, 922JA..., Dukane 110-3122, Rinco brand and so on.
  • For some special items, you can provide us with samples, then we can give you a competitive price and custom-made it for you.
