Timesaving / Flexible Ultrasonic Homogenizer Within A Noise Reducing Enclosure

China Timesaving / Flexible Ultrasonic Homogenizer Within A Noise Reducing Enclosure supplier
Timesaving / Flexible Ultrasonic Homogenizer Within A Noise Reducing Enclosure supplier Timesaving / Flexible Ultrasonic Homogenizer Within A Noise Reducing Enclosure supplier

Large Image :  Timesaving / Flexible Ultrasonic Homogenizer Within A Noise Reducing Enclosure

Product Details:

Place of Origin: CHINA
Brand Name: Altraasonic
Certification: CE
Model Number: HSS17B-ZB

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: Packed in carton, and PE form inside
Delivery Time: 10 working days after received your payment
Payment Terms: T/T
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Name: Ultrasonic Homogenizer Frequency: 20Khz
Power: 1000W Weight: 13Kg

Timesaving / Flexible Ultrasonic Homogenizer Within A Noise Reducing Enclosure



Specifications:



Model

S20-1000

S20-1500

S20-2000

S20-3000

Frequency

20±1 KHz

20±1 KHz

20±1 KHz

20±1 KHz

Power

1000 W

1500 W

2000 W

3000 W

Voltage

220±10% V

220±10% V

220±10% V

220±10% V

Temperature

300 ℃

300 ℃

300 ℃

300 ℃

Pressure

35 MPa

35 MPa

35 MPa

35 MPa

Intensity of sound

>20 W/cm²

>30 W/cm²

>40 W/cm²

>60 W/cm²

Max Capacity

> 10 L/Min

> 15 L/Min

> 20 L/Min

> 30 L/Min

Material Of Tip Head

Titanium Alloy

Titanium Alloy

Titanium Alloy

Titanium Alloy



Ultrasonic Homogenizer

Homogenization are common Sonicator applications. The ultrasonic energy output of each Sonicator model is adjustable and sonication parameters can be optimized according to your process requirements. Amplitude (intensity) can be lowered in order to gently process fragile cells, prevent organelles from being damaged or decrease degradation of enzymes. Amplitude can also be increased to powerful levels to process difficult cell types

Sometimes referred to as Sonicator, Cell Disrupter or Cell Disruptor, Sonifier, Probe Sonicator, Ultrasonic Liquid Processor, and Sonic Dismembrator.




Applications
Prepare Tissue Prepare Emulsions Immiscible Liquids
Accelerate Enzymatic Reactions Accelerate Chemical Reactions Stimulate Bacterial Activity
Disperse Solids De-gas Liquids Deaglomerate Powders
Dissolve Powders Dissolve Tablets Emulsify Cosmetics
Extract DNA / RNA Extract Proteins Emulsify Liposomes




How it Works



The ultrasonic power supply transforms line voltage to high frequency 20 kHz electrical energy. This electrical energy is transmitted to the probe where it is converted to mechanical energy. The vibrations from the probe are coupled to and intensified by the titanium tip. The probe vibrates in a longitudinal direction and transmits this motion to the titanium tip immersed in the solution. Cavitation results, in which microscopic vapor bubbles are formed momentarily and implode, causing powerful infinitesimal shock waves to radiate throughout the solution in proximity to the radiating face of the tip.



Automatic Tuning



All the of our Ultrasonic Homogenizers models employ a propriety feedback system, insuring that the generator is always working at it maximum efficiency regardless of the application. There is no need for constant adjustment by the operator. The percentage of ultrasonic power emitted is indicated by the output LED meter, enabling accurate reproducible results.





Competitive Advantage:



  • Ideal for small samples
  • Practical - The sample can be processed in a microvial and kept cold by immersion in ice.*
  • Mobile - Easy to hold and feather-light. Cordless.
  • Simple to use - Just hold it in a vessel and depress the push-button power switch.
  • Easy to clean - Rinse it under a tap or in a washing up container.

*When sonicating biological samples in a small volume of homogenization buffer heat formation must be aggressively controlled. This caution applies using any brand of sonicator.



Custom sizes available for laboratory and high volume industrial applications.
