Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic

Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic
Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic

Large Image :  Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Model Number: HSTL20-8Z
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Packaging Details: packed in a wooden case
Delivery Time: 7days
Payment Terms: T/T, Western Union
Supply Ability: 5000 pieces/month

Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic

Description
Frequency: 20kHz Output Power: 5000 Watt
Joint Bolt: 1/2-20 UNF Ceramic Disc Diameter: 50 Mm
Capacitance: 23nf Amplitude: 20 Um
High Light:

piezo ultrasonic transducer

,

ultrasonic transducers

Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic





Specifications:



Model HSTL20-8Z
Frequency 20 khz
Output power 5000 watt
Joint bolt 1/2-20 UNF
Ceramic disc Diameter 50 mm
Quantity of Ceramic discs 4 pcs
Capacitance 23nf
Amplitude 20 um
Application Metal welding machine / Plastic welding



Description:



The 5000 Watt 20 KHz Ultrasonic Konverter Direct replacement for the Telsonic machine that delivers lower cost, rugged quality and superior value.

First, all of the parts are all new.

The parts are made from certified materials in tightly controlled manufacturing processes, assembled and

tested in a climate-controlled environment using carefully calibrated equipment, then properly aged and re-tested to ensure

performance that duplicates the OEM part.





Competitive Advantage:



1. Steel back metal body and special aluminum main body.

2. Once assembled, the transducers are aged before testing and final assembly. The properties of piezoelectric materials can change with time and pressure, so a bit of time on the shelf prior to testing will identify nonconforming material.

3. One by one testing to ensure that each transducer performance are excellent.

4. In good heat resistance, can be used in a wide range of temperature with long life and high reliability.



What we can do for you,



1. OEM - special custom-made the ultrasonic transducers or parts for you, and save cost for you.

2. Supply Replacement converter - Including NTK, Branson CJ20, CR20, 922JA..., Dukane 110-3122, Rinco brand and so on.

3. For some special items, you can provide us with samples, then we can give you a competitive price and custom-made it for you.



Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic 0



Silver 20 Khz Ultrasonic Transducer For Replacement Telsonic 1
