High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics

High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics
High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics

Large Image :  High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: 5520-8BZ
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Packed in carton, PE foam inside
Delivery Time: 3 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 10,000 units per month

High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics

Description
Product Name: Ultrasonic Welding Transducer Frequency: 20Khz
Ceramic Diameter: 55MM Capacitance: 17-22.5nf
Power: 6000 Watt Application: Welding Machine
Amplitude: 15 Um Ceramic Disc: 8 Pcs
Material Of Booster: Titanium Material Protective Housing: Aluminum And Stainless Steel Optional
High Light:

piezo ultrasonic transducer

,

ultrasonic transducers



High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz



Description:

The ultrasonic transducer itself is not an energy generator, it is just an energy converter. It converts electrical energy into acoustic energy (mechanical energy), which can convert (output) a large amount of energy under the premise that the input (drive power) and output (amplifier, ultrasonic mold) are well matched. Let the ultrasonic transducer and the ultrasonic generator drive power supply and the ultrasonic mold cooperate well to form a complete ultrasonic device, which can be referred to as matching. Since the impact of matching on the performance of the whole machine is decisive, the importance of matching is not overemphasized. The primary consideration for matching is the capacitance of the transducer, followed by the frequency of the transducer.


Specifications:


Model 5520-8BZ
Frequency 20khz
Output power 6000 watt
Joint bolt M18*1.5
Ceramic disc Diameter 55mm
Qty of ceramic discs 8pcs
Capacitance 17-22.5nf
Amplitude 15 um
Application Plastic welding machine






Competitive Advantage of Altrasonic:


1. Titanium, aluminum, steel materials of horn optional.

2. Once assembled, the transducers are aged before testing and final assembly. The properties of piezoelectric materials can change with time and pressure, so a bit of time on the shelf prior to testing     will identify nonconforming material.

3. One by one testing to ensure that each transducer performance are excellent.

4. In good heat resistance, can be used in a wide range of temperature with long life and high reliability.

5. Superior quality in the Ceramics



Application:



Automotive engine, compartment, functional, components, exterior/light, interior
Electronic sensors, switches, housings, electrical devices, cable and quick disconnect systems
Medical membranes, adaptors, connectors, fluid containers, filters, breathing masks, wound dressing, bandaging material
Consumer household, leisure, garden, toys, office, packaging
Automation industrial, automation, multihead components, flexibte robot cells



FAQ:

1.Q:What effect does the glue on electrode piece of transducer have?

A:This is insulation glue, used for insulation protection.

2.Q:What are the materials of the back cover and front cover of the transducer?

A:It is mainly composed of aluminum and titanium alloys, some of which are made of special steel.

High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics 0



High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics 1







High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics 2





Tag: ultrasonic piezoelectric transducer,high power ultrasonic transducer



High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics 3

High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics 4

High Power Piezoelectric Ultrasonic Welding Transducer 6000w 20Khz 8pcs Ceramics 5
