Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling

China Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling supplier
Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling supplier Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling supplier Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling supplier Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling supplier

Large Image :  Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling

Product Details:

Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HS-M2010

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Packaging Details: Carton or Wooden case
Payment Terms: T/T, Western Union
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Power: 500W Frequency: 20Khz/40Khz
Generator: Digital Application: Ultrasonic Drilling
Components: Digital Generator, Transducer, Booster, Horn

Ultrasonic Multi-Axis Milling For Quartz Glass And Aerospace Machining



Technical Parameters:

Resonance point amplitude: 10um or more;

Max Speed: 30000 RPM

Matching tool: carbide end mill head Φ2-Φ13; disk cutter Φ50;drilling hear Φ1~6

Power: 500W



Frequency 20 Khz/40khz
Output Power 500 W
Voltage 220 V
Switch Handle or foot switch
Power Adjusting Step or continuous
Working Time Control 24 Hours
Weight 30 KG
Application Ultrasonic drilling,milling grinding
Generator Digital Generator
Length of cable 5M





Ultrasonic drilling



Ultrasonic assisted drilling is a recently-developed technique, in which high-frequency (> 20 kHz) vibration is superimposed onto the movement of a standard drill bit in the axial direction, providing advantages including reduced drilling forces (reduction often in excess of 80%) and improved quality of drilled holes when compared to conventional drilling. Ultrasonic assisted drilling also achieves a reduction in entry and exit delamination size, but not in the expected proportion considering the observed reduction of drilling forces. A different mechanical process to that in conventional drilling may be driving the delamination in Ultrasonic assisted drilling, for example dynamic or thermal effects in addition to thrust and torque loads.



Competitive Advantages:

  • Ultrasonic Drilling Machines have been developed in various models equipment.
  • Frequency, power can be real-time monitoring, power 30-99% adjustable, with automatic alarm protection, easy to operate;
  • Less than 4% weight loss in drilling on an average.

Applications

  • Various kinds of materials especially fragile rigid material.
  • Processing plane, groove, all kinds of form surface (such as spline, gear and thread) and special surface of mould.
  • Application area: machining industry, machine tool equipment manufacturing.
  • Application occasion: manufacturing enterprise, universities and colleges, scientific research institution, mechanical equipment transformation industry.

Ultrasonic Multi-Axis Milling For Quartz Glass And Aerospace Machining

Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis MillingQuartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis MillingQuartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling



Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling



Workshop:

Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling



CE Certification:

Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling



Packing&Shipping:



Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis MillingQuartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling





Payment:

Quartz Glass Ultrasonic Assisted Machining Ultrasonic Multi Axis Milling

FAQS



Q:What is rotary ultrasonic assisted machining ?

A:Ultrasonic assisted machining means ultrasonic vibration apply to traditional machine tool for drilling and milling especially ofr hard and brittle materials with perfect performance.





Q:What is ER collet?

A:The ER collet is a subtype of chuck that forms a collar around an object to be held and exerts a strong clamping force on the object when it is tightened, usually by means of a tapered outer collar. It may be used to hold a workpiece or a tool





Q:What is BT40 and HSKA63?

A:These are two different kinds of tool holder which used for connect to your CNC machine according to different size and type.
