300MM Titanium Ultrasonic Food Cutting Machine With Digital Power Control Box

Certification
China Hangzhou Altrasonic Technology Co., Ltd certification
Customer Reviews
The converters corresponding to your INVOICE NO. HS2015021 work very well. We would like to order more

—— Peter

I'm very happy with your good communication skills as well as follow up and good deal. I will definitely inform you my further program for further coo

—— Vinay

We tested it and it worked.  I will let you know about future purchases soon.

—— Alvin

Thank you! It is a pleasure, to work with a company that wants to make it right for the customer :) many times i deal with Chinese companies that do not care about the customer and long term business. I think I made the right decision going with you and Altrasonic !!!

—— Cameron

I'm Online Chat Now

300MM Titanium Ultrasonic Food Cutting Machine With Digital Power Control Box

300MM Titanium Ultrasonic Food Cutting Machine With Digital Power Control Box
300MM Titanium Ultrasonic Food Cutting Machine With Digital Power Control Box 300MM Titanium Ultrasonic Food Cutting Machine With Digital Power Control Box

Large Image :  300MM Titanium Ultrasonic Food Cutting Machine With Digital Power Control Box

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HSFC82
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: Wood case
Delivery Time: 5days
Payment Terms: T/T
Supply Ability: 200 Set per month

300MM Titanium Ultrasonic Food Cutting Machine With Digital Power Control Box

Description
Frequency: 40Khz Material: Titanium
Blade: 82cm Power: 500W
Highlight:

ultrasonic food cutting machine

,

ultrasonic food cutter

82MM Titanium Ultrasonic Food Cutting Machine With Digital Power Control Box



Description:



Ultrasonic cutters can smoothly cut difficult-to-cut materials.
They are small in size and do not require large installation areas. Special equipment is not required for the installation. They are small enough to be hand-held for many operations. They can also be attached to automated machinery arms. Although they may not be familiar to you, they play an active role in the manufacturing processes of various industrial products which we use daily.

The ultrasonic cutter is composed of a “transducer” that generates vibration and an “oscillator” that drives the transducer. A piezoelectric element is used for the transducer. When voltage is applied, the piezoelectric element displaces the transducer by a few micrometers. Periodically applying voltage generates vibration. Each object has its special frequency, by which the object is stable and easy to vibrate. By adding an external force that corresponds to that special frequency, a small force can obtain a large vibration. This phenomenon is called resonance.

In the ultrasonic cutter, the piezoelectric element generates a force that resonates the whole body, from the transducer to the blade tip, generating a large vibration at the tip. The oscillator periodically generates voltage to resonate and drive the transducer. Using a component of the ultrasonic cutter called the horn to wring the cross-sectional area, from the piezoelectric element to the blade tip, can obtain a larger vibration.



Ultrasonic cutting advantage and features:



1. Cut the material quickly and precisely
2. Smooth and traceless cutting edge
3. Powerful, effective realiable
4. Low cost, easy operator. An operator only handle the probe and step the foot switch .So anybody can use it easily.





FREQUENCY

40Khz

POWER

500W 800W

INPUT

AC110-240V, 50/60Hz

POWER CONTROLLER

stepping or continuous

MATERIAL OF CUTTING HEAD

aluminum alloy, stainless steel, titanium alloy, alloy steel.

MACHINE WIGHT

4 kg-16KG

ACCESSORIES

foot switch, additional blade

COOLING DEVICE

compressed air mouth can be installed.

CABLE LENGTH

2M or customized

FOOT SWITCH

available







Applications:



1. For thermal plastic gate cutting and flush cutting.

2. For non-woven or woven cutting,textile cutting, fabric cutter, curtain cutting,window blind fabric
3. For rubber, PVC, leather plastic, cardboard, acrylic, polyprolene and so on cutting.
4. For tape and film cutting .
5. For paper cutting,printing industry cutting.

6. For package material cutting

7. For  the automotive industry cutting



82MM Titanium Ultrasonic Food Cutting Machine With Digital Power Control Box
