35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton

35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton
35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton 35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton 35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton

Large Image :  35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HS-W35
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Packed in cotton with foam inside
Delivery Time: 7 work days
Payment Terms: T/T, Western Union

35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton

Description
Frequency: 35khz Max. Output Power: 1000watt
Application:: Welding Acoustic Cotton Power Supply: Digital
Rated Current: 10A Welding Time Range: 0.05s-10s
Weight: 110kg Ambient Temperature: 5-50℃
High Light:

plastic spot welder

,

ultrasonic plastic welder

35kHz Automation Ultrasonic Welding Machine For Bonding Automotive Acoustic Cotton



Description:



The HS-W35 series of ultrasonic welder offer a compact design to conserve work space,and is easy for operation and maintenance to achieve an outstanding cost-performance.

The HS-W35 series of ultrasonic welder is using a mechanical control and accurate duplication of welder parameters setting design for a more stable and reliable weld performance, suitable for more industrial applications.



Technical Parameters:



Item No HS-W35
Frequency 35Khz
Power 1000W
Voltage 110V-240V, Alternating current
50-60hz, Single phase
Electric current 10A
Range of welding time 0.05-10/sec
Environment Temperature 5-50℃
Air supply requirements Clean dry compressed air, maximum pressure 7kg
Maximum pressure 1.96KN
Maximum stroke 100MM
Beats 80CPM
Operated mode Time mode or Energy mode
Weight 110Kgs



Ultrasonic Welding Principle:



When ultrasonic effects on the contact area of thermoplastic plastic, it will produce tens of thousands times per second high-frequency vibration. This the high-frequency vibration achieves a certain amplitude, and passes the ultrasonic energy to the welding area through the welding pieces. Because of the large resistance at the interface of the two welding area, it will produce local high temperature. And also because of poor thermal conductivity of plastic, can not be distributed in time, gathered in the welding area, resulting in two plastic contact surface rapid melting, coupled with a certain pressure, to integrate into one. When the ultrasonic stops, let the pressure last for a few seconds to make it solidified, thus forming a solid molecular chain, to achieve the purpose of welding, welding strength can be close to the strength of raw materials. The quality of ultrasonic plastic welding depends on the amplitude of the transducer and the horn, the welding pressure and the welding time. The welding time and welding horn pressure can be adjusted. The amplitude depends on transducer and booster. The three factors of interaction have a suitable value, if the energy exceeds the appropriate value, the plastic melting amount will be large, easy to deformation of welding; if the energy is small, it is not easy to solder, the pressure can not be too much. This optimum pressure is the product of the length of the welded part and the edge of the optimum pressure per 1mm.



Main advantages:



  1. High Amplitude to adjusting different plastic material welding.
  2. Exclusive system protection monitor module.
  3. Self test and automatic frequency search.
  4. Dynamic Triggering to provide consistent welding result



WHY CHOOSE ALTRASONIC ?



1. OVERSEA SERVICE TEAM. We now have agents in India, Austrilia, Hongkong, Singapore, Taiwan, Malaysia, Germany, and other country still being discussing.

2. Innovation. Altrasonic R&D and marketing staffs to constantly explore new applications in the field of ultrasound, and the importance of team spirit of cooperation.

3. Half the price, double the value. Every product reach you have been test in our company three times, and with 72 hours continous working, to confirm it is well before you get it. Also we always learn from foreign company, to upgrade our products.

4. Good components. Ceramic mainly imported from German, and using the superior quality aluminum, titanium raw materials.

5. Individual Customize. We can customize products according to your requirements, Also supply OEM service. Customize ultrasonic solution for different applications.







35kHz Automation Ultrasonic Welding Machine For Bonding Automotive Acoustic Cotton



35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton 0

35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton 1

35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton 2

35kHz Ultrasonic Plastic Welding Machine For Bonding Automotive Acoustic Cotton 3
