30Khz Robotic Ultrasonic Spot Welding Machine for Automobile Carpet

30Khz Robotic Ultrasonic Spot Welding Machine for Automobile Carpet
30Khz Robotic Ultrasonic Spot Welding Machine for Automobile Carpet 30Khz Robotic Ultrasonic Spot Welding Machine for Automobile Carpet 30Khz Robotic Ultrasonic Spot Welding Machine for Automobile Carpet

Large Image :  30Khz Robotic Ultrasonic Spot Welding Machine for Automobile Carpet

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HS-GT28
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 7 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 3000 units per month

30Khz Robotic Ultrasonic Spot Welding Machine for Automobile Carpet

Description
Product Name: Ultrasonic Spot Welding Machine Frequency: 28Khz
Power: 1000W Inlet Power: AC220V±10V Or AC110V±10V , 50/60HZ
Auotomatic Resonance Frequency Range: ±1000hz Working Environment: +5~+50℃
Keeping Environment: -5~+70℃ Net Weight: 8-12Kgs
Max Current: 15A
High Light:

portable spot welding machine

,

sonic welding machine

30Khz Robotic Ultrasonic Welding Machine for Welding Automobile Carpet



Specifications:

Model HS-40 HS-35 HS-30 HS-28 HS-20
Frequency 40khz 35khz 30khz 28khz 20khz
Power 500W 500~800w 500~800w 500~800w 500~1000w
Horn ≤10mm ≤10mm ≤10mm ≤12mm ≤13mm
Housing Diameter 44mm 44mm 44mm 44mm 64mm
Weight of Welder 1.0kg 1.0kg 1.0kg 1.0kg 1.5kg





Main Advantages :

  1. Maintain the amplitude function automatically
  2. Starting: achieving maximum power with 105msec
  3. Application in riveting, forming and welding
  4. Light weight, easy to take, easy to operate (handheld)
  5. Equipped with welding timer
  6. Easty to set time welding
  7. Equipped with an overload protection circuit( Voltage, current, phase, temperature, output)
  8. FET power output
  9. Automatic resonance

Automobile Carpet Welding  Principle:
When the ultrasonic role in the thermoplastic plastic contact surface, it will generate tens of thousands of times per second, high frequency vibration, this high-frequency vibration, ultrasonic energy through the ultrasonic wave transmitted to the mold to ultrasonic welding material surface, it will produce high-temperature materials. Plastic contact surface resulting in rapid melting, coupled with stress, it blend and coagulation, so that to achieve the purpose of ultrasonic welding.



Applications In Automobile:

Ultrasonic Spot Welding is mainly used in automotive interior parts. Ultrasonic spot welding in sound-proof cotton of engine cover, trunk and wheel casing, and hallstand felt. Ultrasonic Riveting Welding can be used in automobile air-conditioning outlet welding, car rear view mirror, car door handles, hand car door and so on.Automotive plastic parts are mostly welded in non-standard ultrasonic welding equipment, long multi-station design, with PCL program control and LCD operation, large automotive complex workpiece welding, including different directions of the welding surface, in multiple locations.



Components and Amplifying Principle

Components of Ultrasonic Welding (Horn, Booster and Transducer)

They can amplify the amplitude at a particular ratio step by step. For example, the transducer amplitude is 6mm, the booster can amplify it triply to 18mm, and then the horn can make it to 36mm. However, the work life of horn would be shortened with the amplification of amplitude. The required amplitude differs with the welding material.



30Khz Robotic Ultrasonic Welding Machine for Welding Automobile Carpet



30Khz Robotic Ultrasonic Spot Welding Machine for Automobile Carpet 0



30Khz Robotic Ultrasonic Spot Welding Machine for Automobile Carpet 1
