255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad

255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad
255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad 255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad 255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad 255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad 255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad

Large Image :  255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad

Product Details:
Place of Origin: CHINA
Brand Name: Altrasonic
Certification: CE
Model Number: HSFC255
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Packaging Details: Wood case
Delivery Time: 7 work days
Payment Terms: T/T, Western Union
Supply Ability: 200 Set per month

255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad

Description
Frequency: 20Khz Blade: 255mm
Material: Titanium Power: 800W
Application: Bakery And Snack Food Cutting
High Light:

ultrasonic food cutting machine

,

food cutting equipment

255mm Ultrasonic Food Portioning Cutter with Titanium Blade Designs for Long Life and Amplitude Accuracy



Description:



The ultrasonic food cutting machine (cutter) is composed of ultrasonic transducer (converter) with cover, booster, titanium blade and digital generator.

Ultrasonic cutters can smoothly cut difficult-to-cut materials.
They are small in size and do not require large installation areas. Special equipment is not required for the installation. They are small enough to be hand-held for many operations. They can also be attached to automated machinery arms. Although they may not be familiar to you, they play an active role in the manufacturing processes of various industrial products which we use daily.

The ultrasonic cutter is composed of a “transducer” that generates vibration and an “oscillator” that drives the transducer. A piezoelectric element is used for the transducer. When voltage is applied, the piezoelectric element displaces the transducer by a few micrometers. Periodically applying voltage generates vibration. Each object has its special frequency, by which the object is stable and easy to vibrate. By adding an external force that corresponds to that special frequency, a small force can obtain a large vibration. This phenomenon is called resonance.

In the ultrasonic cutter, the piezoelectric element generates a force that resonates the whole body, from the transducer to the blade tip, generating a large vibration at the tip. The oscillator periodically generates voltage to resonate and drive the transducer. Using a component of the ultrasonic cutter called the horn to wring the cross-sectional area, from the piezoelectric element to the blade tip, can obtain a larger vibration.



Parameters:

FREQUENCY 20Khz
POWER 800W
INPUT AC110-240V, 50/60Hz
POWER CONTROLLER stepping or continuous
MATERIAL OF CUTTING HEAD Titanium alloy
MACHINE WIGHT 15~18KG
COOLING DEVICE compressed air mouth can be installed.
CABLE LENGTH 3M or customized
FOOT SWITCH available





Features of Different Cutting Equipment



Cutter Type Bottom Type
More than 10 times speed than ordinary cutter
Stable work for a long time
Customizing cutting of related shape according to client’s requirement
Available on the producing of disk-shaped ultrasonic cutter equipment, realizing the rolling cutting
Cutting something uncutable for normal cutters Cutting all kinds of fabric, clothes, plates and so on.
Decreasing cost for its replaceable blade Harden process; more than 20000 meters effective cutting length
Easy to install and use and the previous cutting technology can be reserved Easy to install and suitable for ordinary cutter



Advantages:

  • High energy conversion efficiency, more than 90%;
  • The vibration of the ultrasonic food processing system using high frequency wave to quickly cut food;
  • Provides a new way to cut piece, cutting, steering, and transfer alignment or different kinds of food;
  • Makes the cost of production flow minimization;
  • Especially for cutting high viscosity food;
  • Cutting is very hygienic;
  • The cut food looks neat and beautiful;
  • Suitable for automated assembly line, do not have to make a lot of changes to the original line, saving production costs.





255mm Ultrasonic Food Portioning Cutter with Titanium Blade Designs for Long Life and Amplitude Accuracy



255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad 0255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad 1255mm 20Khz 800W Ultrasonic Food Portioning Cutter With Titanium Blad 2
