20Khz Ultrasonic Spot Welding Machine Ultrasonic Cap With Titanium Material

China 20Khz Ultrasonic Spot Welding Machine Ultrasonic Cap With Titanium Material supplier
20Khz Ultrasonic Spot Welding Machine Ultrasonic Cap With Titanium Material supplier 20Khz Ultrasonic Spot Welding Machine Ultrasonic Cap With Titanium Material supplier

Large Image :  20Khz Ultrasonic Spot Welding Machine Ultrasonic Cap With Titanium Material

Product Details:

Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HS-PT20

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 7 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 3,000 units per month
Contact Now
Detailed Product Description
Product Name: 20 Khz High Power Portable Ultrasonic Spot Welder , 1000 Watt Frequency: 20Khz
Frequency Tuning Method: Auto Tuning Power: 1000W
Components: Ultrasonic Transducer, Welding Horn, Protective Sleeve And Digital Generator Horn: Working Surface Diameter 9-10mm, Steel Material
Application: Auto Parts Welding Welding Type: Hand Held Operation
Net Weight: 10kgs

Ultrasonic Cap Welding 20Khz titanium circular Horn welding equipment​



Description:



Independent research and development on power hand-held ultrasonic spot welding machine with 28K, 35K, 30K three different frequencies. Can be different for the following purposes;

Ultrasonic welding: ultrasonic vibration with ultrasonic welding mould, the ultrasonic welding energy conduction to the plastic surface, resulting in local temperature, so that the plastic surface melting. Under the pressure of the ultrasonic hand, so to weld plastic, beautiful, strong effect.

Ultrasonic implants: the nut screws or other metal into plastic
work piece. Ultrasonic energy through the ultrasound machine will be transmitted to the metal. The high-speed vibration and heat, the pressure in the ultrasound machine to make metal objects embedded directly into the plastic inside.

Ultrasonic riveting: the nature of metal and plastic or two different plastic bonding together, can make use of ultrasonic riveting machine, so that the weldment hard brittle, beautiful, strong.

Ultrasonic welding: the use of ultrasound machine small welding head, the two pieces of plastic products into multi-point welding, or welding the first row of teeth on a direct pressure on the two plastic
work piece, so as to achieve the effect of ultrasonic welding.

Portable Ultrasonic Plastic Spot welding gun principle:
When the ultrasonic role in the thermoplastic plastic contact surface, it will generate tens of thousands of times per second, high frequency vibration, this high-frequency vibration, ultrasonic energy through the ultrasonic wave transmitted to the mold to ultrasonic welding material surface, it will produce high-temperature materials. Plastic contact surface resulting in rapid melting, coupled with stress, it blend and coagulation, so that to achieve the purpose of ultrasonic welding.



ITEM  HS-PT20
Frequency 20Khz
Power 2000W
Material titanium
Application Cap welding



Competitive Advantage:



Rapid sonotrode exchange

High quality, heavy duty aluminum housing

High frequency and control cable to the ultrasound generator are in a strong and highly flexible braided plastic sheet

Timer-controlled air cooling as an option

Mobile – can be transported by handle on the generator case



Ultrasonic Cap Welding 20Khz titanium circular Horn welding equipment​



20Khz Ultrasonic Spot Welding Machine Ultrasonic Cap With Titanium Material

20Khz Ultrasonic Spot Welding Machine Ultrasonic Cap With Titanium Material

20Khz Ultrasonic Spot Welding Machine Ultrasonic Cap With Titanium Material
