220V Thermoplastics Ultrasonic Plastic Welding Machine For Toy Gun / Disguise Box

220V Thermoplastics Ultrasonic Plastic Welding Machine For Toy Gun / Disguise Box
220V Thermoplastics Ultrasonic Plastic Welding Machine For Toy Gun / Disguise Box 220V Thermoplastics Ultrasonic Plastic Welding Machine For Toy Gun / Disguise Box 220V Thermoplastics Ultrasonic Plastic Welding Machine For Toy Gun / Disguise Box 220V Thermoplastics Ultrasonic Plastic Welding Machine For Toy Gun / Disguise Box

Large Image :  220V Thermoplastics Ultrasonic Plastic Welding Machine For Toy Gun / Disguise Box

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HS-X20P
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 7 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 200 units per month

220V Thermoplastics Ultrasonic Plastic Welding Machine For Toy Gun / Disguise Box

Description
Production Name: Plastic Assembly Technologies, Ultrasonic Welding Of Thermoplastics Frequency: 15Khz
Output Power: 2600W Welding Capability: 160 ~ 200 M/m φ
Net Weight: 110 Kg Line Source: 220V 10A / 220V 15A
High Light:

plastic spot welder

,

plastic ultrasonic welding

220V Thermoplastics Ultrasonic Plastic Welding Machine For Toy Gun / Disguise Box



Description:



Ultrasonic welding equipment can be easily customized to fit the exact specifications of the parts being welded. The parts are sandwiched between a fixed shaped nest (anvil) and a sonotrode (horn) connected to a transducer, and a ~20 kHz low-amplitude acoustic vibration is emitted. (Note: Common frequencies used in ultrasonic welding of thermoplastics are 15 kHz, 20 kHz, 30 kHz, 35 kHz, 40 kHz and 70 kHz). When welding plastics, the interface of the two parts is specially designed to concentrate the melting process. One of the materials usually has a spiked energy director which contacts the second plastic part. The ultrasonic energy melts the point contact between the parts, creating a joint. This process is a good automated alternative to glue, screws or snap-fit designs. It is typically used with small parts (e.g. cell phones, consumer electronics, disposable medical tools, toys, etc.) but it can be used on parts as large as a small automotive instrument cluster.



Applications:



Toy industry: such as toy gun, water gun, telephone and rag baby etc.

Electronic industry: The gum case of watch, nylon watch band, calculator, sound box wraps hull, cell phone battery etc.

Car industry: Car light.

Pack an industry: Disguise box, PVC packing box, toothpaste tube etc.

General business ware: The typewriter color take, video cassette rack, tape box, computer disk etc.



Specifications:



Item No HS-X20P HS-X15P
Frequency 20Khz 15Khz
Power 1500W 3300W
Voltage 200-240V, Alternating current 200-240V,Alternating current
50-60hz, Single phase 50-60hz, Single phase
Electric current 10A 20A
Range of welding time 0.05-10/sec 0.05-10/sec
Environment Temperature 5-50℃ 5-50℃
Air supply requirements Clean dry compressed air, maximum pressure 7kg Clean dry compressed air, maximum pressure 7kg
Maximum pressure 1.96KN 2.89KN
Maximum stroke 100MM 100MM
Beats 80/Min 50/Min
Triggered Dynamic range 67-890N 135-990N
Weight 66Kgs 68Kgs
Dimension 476mm(L)*736mm(W)*1524mm(H) 476mm(L)*736mm(W)*1524mm(H)




Competitive Advantage:



Service: Timely feedback; Free design; 1 year Warranty.

Quality: Full testing before shipping; we reputation from customer.
