Graphene Oxide Ultrasonic Sonochemistry Treatment , Portable Homogenizer Remote Controlled

China Graphene Oxide Ultrasonic Sonochemistry Treatment , Portable Homogenizer Remote Controlled supplier
Graphene Oxide Ultrasonic Sonochemistry Treatment , Portable Homogenizer Remote Controlled supplier Graphene Oxide Ultrasonic Sonochemistry Treatment , Portable Homogenizer Remote Controlled supplier Graphene Oxide Ultrasonic Sonochemistry Treatment , Portable Homogenizer Remote Controlled supplier

Large Image :  Graphene Oxide Ultrasonic Sonochemistry Treatment , Portable Homogenizer Remote Controlled

Product Details:

Place of Origin: CHINA
Brand Name: Altrasonic
Certification: CE
Model Number: HS205-L

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: Packed in wooden carton
Delivery Time: 10 working days after received your payment
Payment Terms: T/T
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Name: Ultrasonic Sonochemistry Frequency: 20Khz
Power: 3000W Weight: 35Kg
Generator: Digital Mode Control: Remote Control
Application: Dispersing Probe: Different Size And Type Optional
Capacity: More Than 100L

Graphene Oxide Ultrasonic Sonochemistry Treatment , Portable Homogenizer Remote Controlled


Altrasonic equipment focused on the r&d of high power ultrasound applications. Altrasonic has absolute

leading core technology, the most stable and mature manufacturing technology, rich experience, can provide

direct ultrasonic application scheme demonstrate, structure design, system configuration and related parts production.
Altrasonic equipment cooperated with the key graphene manufacturers, applied the ultrasound equipment in graphene

preparation process of industrialization firstly, and make the ultrasonic be a good supporting to the large-scale preparation of the high quality and low cost graphene materials.





Lab level



Recommendation of ultrasonic system (exfoliated type)



Item No. HS205-L HS2020-L
Capacity 5L 20L
Output power 500W 2000W
Main advantages High output intensity, high cavitation effect
Frequency 20 kHz±1kHz




Recommendation of ultrasonic system (Dispersing type)





Item No. HS2010 HS2015 HS205-F HS2010-F HS2020-F
Capacity 20L 30L 10L 20L 30L
Output power 1000w 1500w 500w 1000w 2000w
Frequency 20 kHz±1kHz 20 kHz±1kHz 20 kHz±1kHz 20 kHz±1kHz 20 kHz±1kHz
Working type Reactor / container Reactor / container

Recycling

/ Flow chamber

Recycling

/ Flow chamber

Recycling

/ Flow chamber





Recommendation of ultrasonic machine (Industrial level)



Ultrasonic Probe / Ultrasonic digital generator / Control system assembly / Reactor assembly / Rack and pipe fittings



Item No. HS-GS10 HS-GS25 HS-GS50 HS-GS100 HS-GS200 HS-GS300
Annual output

10tons

25tons 30tons 100tons 200tons 300tons
Output Power

2000w

2000w 2000w 2000w 2000w 2000w
Total Power

6000w

(2000w*3)

12000w

(2000w*6)

24000w

(2000w*12)

48000w

(2000w*24)

72000w

(2000w*36)

96000w

(2000w*48)

Frequency

20kHz±1kHz

20kHz±1kHz 20kHz±1kHz 20kHz±1kHz 20kHz±1kHz 20kHz±1kHz
Input Voltage

110v  or 220v

110v  or 220v 110v  or 220v 110v  or 220v 110v  or 220v 110v  or 220v
Total Volume

5㎡

10㎡

20㎡ 40㎡ 60㎡ 80㎡





Graphene With Ultrasonic



Currently we use two step exfoliation can obtain high concentration graphene dispersion, second ultrasound in 30 hours

reached the max concentration ---- 20 mg/ml, the instantaneous concentration as high as 63 mg/ml.
After using various methods, the graphite expansion and the space between graphene sheets increases, the vader Waals

between interlayers reduce, at the same time use the liquid phase exfoliation can make graphene production rate greatly

increased, and also can use water as solvent to obtain graphene, has a broad  industrial prospect.Up to now, several

companies use this way to achieve large production of graphene.

Through ultrasonic equipment, the surface of graphene reach 500 ~ 1000 m2 / g, thickness in 0.55 ~ 3.74 nm,

the purity is more than 95 wt %, straight in: 0.5 3 microns, layer number less than 10.





Innovation:

  1. T caps use replaceable, solve the problem of the tool head cavitation, T caps normal working hours more than 800 hours.
  2. Using the high-power ultrasonic transducer (1500w - 3000w), More stable performance, normal service life more than 10000 hours.
  3. Use of the digitally controlled power, to ensure that all the time in the best condition.
  4. Dumbbell-type tool head design, greatly improving the ultrasonic radiation power per unit area.
  5. The integrated piping made of stainless steel #316.
  6. Overall liquid flow-controllable
  7. Use network-based CAN-bus technology, all working parameters can have room remote control.







WHY CHOOSE ALTRASONIC ?





  1. OVERSEA SERVICE TEAM. We now have agents in India, Austrilia, Hongkong, Singapore, Taiwan, Malaysia, Germany, and other country still being discussing.
  2. Innovation. Altrasonic R&D and marketing staffs to constantly explore new applications in the field of ultrasound, and the importance of team spirit of cooperation.
  3. Half the price, double the value. Every product reach you have been test in our company three times, and with 72 hours continous working, to confirm it is well before you get it. Also we always learn from foreign company, to upgrade our products.
  4. Good components. Ceramic mainly imported from German, and using the superior quality aluminum, titanium raw materials.
  5. Individual Customize. We can customize products according to your requirements, Also supply OEM service. Customize ultrasonic solution for different applications.



20khz , remote control , Preparation by Ultrasonic Treatment of Graphene Oxide
