Welding Machine Ultrasonic Power Supply Adjustable Innovative Plug And Play

Welding Machine Ultrasonic Power Supply Adjustable Innovative Plug And Play
Welding Machine Ultrasonic Power Supply Adjustable Innovative Plug And Play Welding Machine Ultrasonic Power Supply Adjustable Innovative Plug And Play Welding Machine Ultrasonic Power Supply Adjustable Innovative Plug And Play

Large Image :  Welding Machine Ultrasonic Power Supply Adjustable Innovative Plug And Play

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Certification: BV
Model Number: HS-G2030
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Packed in wooden carton, and PE form inside
Delivery Time: 7 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 3,000 units per month

Welding Machine Ultrasonic Power Supply Adjustable Innovative Plug And Play

Description
Product Name: Innovative Plug-and-play Ultrasonic Digital Generator Frequency: 20Khz
Frequency Tuning Method: Auto Tuning Output Power: 3000W
Power Adjusting Method: 30%-99% Voltage: 220V
Net Weight: 10kgs
High Light:

ultrasonic generator

,

ultrasound power supply


Welding Machine Ultrasonic Power Supply Adjustable Innovative Plug And Play


Description:

The principle of ultrasonic welding by the ultrasonic digital generator 50/60 Hz current is converted into 15,20,30 or 40 kHz energy. The high frequency electrical energy is converted by the transducer is again converted into a mechanical movement of the same frequency, followed by the mechanical motion transmitted to the weld head through a set can change the amplitude modulator means. The welding head will be received by the vibration energy transmitted to the engaging portion of the workpiece to be welded, in the region, the vibration energy is by friction by conversion into heat, the plastic melts. Ultrasonic can not only be used to weld the hard thermoplastic fabrics and films can also be processed.

Applications:

Matching with Ultrasonic welding machine
Matching with Ultrasonic cutting machine

Specifications:



Model

HS - G2030

Frequency

20khz

Output power

3000watt

Frequency tuning method

Auto tuning

Automatic frequency adjustment range

±2

Power adjustable

30%-99%

Frequency adjustable

10%-99%

Net weight

10kgs

Application

Welding


Competitive Advantage:


1. High stability: All-digital integrated circuits, use of US imports of processors interference, simplify the hardware structure, improving the reliability of the system.

2. Automatic frequency tracking.

3. Strong output: The use of IGBT power modules plus his excited oscillation circuit structure, the output power is more than 1.5 times that of conventional self-excited circuit.

4. Amplitude stepless adjustment: Amplitude setting range from 10% to 100%.

5. Intelligent three protection and fault alarm: Die-current protection, frequency offset protection, total output is too large to protect. Equipment failure, the generator will stop working, and make the appropriate cause of function prompts until technician troubleshooting.

6. Intelligent closed-loop amplitude control technology to achieve the amplitude adjustment, independent of input supply voltage and load fluctuations affect the amplitude of the output remains constant.

7. Two kinds of welding mode: switch back and forth, so that a higher precision welding, soldering and better results.


Comparison:





Analog generator

Digital generator

Circuit

Analog circuit, discrete components

Digital circuit, the chip control

Automatic search

×

Automatic frequency tracking

×

Frequency adjustment range

±0.15 KHz

±0.5 KHz

Power regulation

×

24 hours of continuous work

×

Non resonant condition

×

LCD

×

Add the PLC protocol

×

Automatic circuit protection

Bad, easy to cause the damage of components

Good

Repair method

Professional repair

Module replacement
