Product Details:
|
| Frenquency: | 20-150Khz | Shipping: | TNT DHL UPS FEDEX |
|---|---|---|---|
| Color: | Yellow | Warranty: | 1 Year |
| Shape: | Simicircle | Life Time: | 4000 Hours |
| High Light: | Ultrasonic Doppler Piezoelectric Ceramic,Ultrasonic PZT Ceramics,Semicircle Piezoelectric Ceramic |
||
Piezoelectric ceramic ultrasonic Doppler for dynamic detection ultrlasonic PZT ceramics
Description:
Using the piezoelectric ceramic ultrasonic Doppler effect, the ultrasonic transmitter circuit drives the electroacoustic transducer to emit ultrasonic waves, and the ultrasonic probe is placed close to the abdominal wall to face the fetal heart, and the transducer can receive the reflected ultrasonic waves and convert it into electricity. The signal is the ultrasonic echo signal. According to the Doppler effect, the echo signal of the ultrasound hitting a moving object will inevitably generate a frequency shift δ. After the echo signal is amplified by high frequency, the input demodulation circuit demodulates the frequency shift δ representing the fetal heart sound. This enables dynamic detection of the fetus.
| Products | Sizes | Resonant Frequency (MHz) | ResonantImpedance(R) | Capacitance (pF) | Dielectric dissipation factor tgδ(Kt) |
| Fetal Doppler Monitor Ceramic | MR-20*10-2.5BY | 2600-3100 | 2.5±0.05 | 0.85±0.01 (0.84-0.87) |
|
| Fetal Doppler Monitor Ceramic | MR-25*12.5-2.5BY | 3100-4100 | 2.5±0.05 | 0.94±0.01 (0.92-0.95) |
≥0.3 |
| Sizes(MM) OD*ID*Thickness | Capacitance (pF) | Frequency (kHz) |
Dielectric dissipation factor tgδ(%) | Coupling factor Kp (%) | Qm |
| φ15*6X2 | 1080 | 92 | 0.4 | 60 | 80 |
| φ4*φ2*2.5 | 45 | 347 | 0.3 | 60 | 1000 |
| φ10*φ5*2 | 350 | 145 | 0.3 | 60 | 1000 |
| φ20*φ10*5 | 1000 | 50.9 | 0.3 | 60 | 1000 |
| φ25*φ10*5 | 1000 | 62.5 | 0.3 | 60 | 1000 |
| φ25*φ9.5*5 | 1000 | 60 | 0.37 | 60 | 1000 |
| φ25*φ10*3 | 1600 | 61 | 0.3 | 60 | 1000 |
| φ25*φ9.5*3 | 1650 | 61.8 | 0.3 | 60 | 1000 |
| φ25*φ10*3 | 1600 | 60 | 0.3 | 60 | 1000 |
| φ30*φ12*5 | 1400 | 51 | 0.31 | 60 | 1000 |
| φ30*φ12*4.5 | 1350 | 53.5 | 0.32 | 60 | 1000 |
| φ30*φ8*5 | 1550 | 56.5 | 0.35 | 60 | 1000 |
| φ32*φ9.5*6 | |||||
| φ35*φ15*5 | 1905 | 43.6 | 0.3 | 60 | 1000 |
| φ35*φ15*5.5 | 1760 | 42 | 0.36 | 60 | 1000 |
| φ36*φ10*4.5 | 2537 | 47.5 | 0.34 | 60 | 1000 |
| φ38*φ15*5 | 2370 | 40.7 | 0.3 | 60 | 1000 |
| φ38*φ15*6 | 2000 | 41 | 0.35 | 60 | 1000 |
| φ38*φ13*6.35 | 1900 | 43 | 0.32 | 60 | 1000 |
| φ38*φ15*6.35 | 1870 | 40.8 | 0.3 | 60 | 1000 |
| φ45*φ15*5 | 3500 | 37.5 | 0.42 | 60 | 1000 |
| φ45*φ15*6.35 | |||||
| φ50*φ17*5 | 4400 | 32 | 0.32 | 60 | 1000 |
| φ50*φ17*6.5 | 3300 | 32.8 | 0.3 | 60 | 1000 |
| φ50*φ20*3 | |||||
| φ50*φ20*6 | 3400 | 32 | 0.3 | 60 | 1800 |
| φ50*φ20*6.5 | 3200 | 32 | 0.3 | 60 | 1800 |
| φ50*φ20*7 | 2900 | 31 | 0.3 | 60 | 1000 |
| φ60*φ30*10 | 2500 | 23.8 | 0.3 | 60 | 1000 |
| φ65*φ30*10 | 3000 | 22.7 | 0.3 | 60 | 1000 |
