Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths

Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths
Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths
Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths

Large Image :  Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths

Product Details:
Place of Origin: CHINA
Brand Name: Altrasonic
Certification: CE
Model Number: HS-C40
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiation
Packaging Details: Inner bubble wrap, then put in a carton box
Delivery Time: 8-10 workdays
Payment Terms: T/T, Western Union
Supply Ability: 5,000 units per month

Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths

Description
Saw Blade Diameter: 5mm Knife: Replaceable
Frequency: 40khz Size Of Generator: 155 X 265 X 170mm
Outer Skin: Aluminum Type: Rubber Cutting Machine
Power: 100w Length Of Cable:: 3M
High Light:

40khz portable ultrasonic cutter

,

100w portable ultrasonic cutter

,

Replaceable Blades portable ultrasonic cutter

Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths



Specification:



Model HS-C40
Frequency 40KHZ
Output Power 100W
Generator Analog generator, 155 x 265 x 170mm
Handle Φ32×170
Size of cutter Blade replaceable
Length of cable 3M
Outer skin Aluminum
Weight 8KG
Voltage 220V / 110V
Accessory Foot switch1pc;Cut blade 25pcs;1.5mm special hex wrench 1pc;
Screw M3×4L 2pcs
Material of cutter

titanium alloy, stainless steel





Introduction:



Ultrasonic cutting does not require a sharp edge, nor does it require a lot of pressure, and will not cause chipping or breakage of the material being cut. At the same time, because the cutting knife is doing ultrasonic vibration, the friction resistance is very small, and the material to be cut is not easy to stick to the blade. This is particularly effective for cutting viscous and elastic materials, frozen materials such as food, rubber, etc., or objects that are inconvenient to apply pressure.



Application:



1. Plastic and thermoplastic door cutting and punching.

2. Cutting for non-woven fabric or weaving, textile cutting, garment lace and fabric cutting. Edges are cut while the edges are cut.

3. Artificial resin, rubber cutting, raw rubber, soft rubber cutting.

4. Tape and all kinds of film cutting.

5. Paper cutting, printing industry cutting, printed circuit board, trademark.

6. Cutting food and plants, such as frozen meat, candy, chocolate.

7. For PVC, rubber, leather, plastic, cardboard, acrylic, polypropylene, etc.

8. Clothing fabric cutting

9. Cutting of packaging materials

10. Cut curtains, blackout fabrics

11. Cutting in the automotive industry



Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths 0Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths 1



Transport and packaging:



Replaceable Blades Portable Ultrasonic Cutter For Nonwoven Cloths 2
