20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine

20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine
20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine 20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine 20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine 20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine 20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine 20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine

Large Image :  20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Model Number: HSFC305
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Packaging Details: Packed in wooden boxes
Payment Terms: T/T, Western Union,PayPal
Supply Ability: 3000 pieces/month

20 KHz Ultrasound Transducer Ultrasonic Cake Cutter Food Cutting Machine

Description
Frequency: 20KHz Power: 800watt
Length Of Blade: 125/255/305mm Or Customized Generator: Digital, Auto -tuning
Machine Weight: 15-18kg Input: AC110-240V, 50/60Hz
Cable Length: 3M Or Customized
High Light:

ultrasonic food cutting machine

,

ultrasonic food cutter

20kHz ultrasound transducer ultrasonic cake cutter food cutting machine





Specification:



Frequency 20Khz
Power 800W
Input AC110-240V, 50/60Hz
Power Controller stepping or continuous
Length of the blade 255mm
Material Of Cutting Head stainless steel, titanium alloy, alloy steel.
Machine Wight 15~18KG
Accessories foot switch, additional blade
Cooling Device compressed air mouth can be installed.
Cable Length 3M or customized
Foot Switch available





The difference between traditional cutting and ultrasonic cutting


Ultrasonic cutting machine is the use of wave energy for cutting equipment, the main t feature is not to use the traditional edge.
The traditional cutting utilizes a tool with a sharp edge to press the cutting material. The pressure is concentrated at the edge of the blade, the pressure is very large, more than the shear strength of the cutting material , then the material is cut open. As the material is cut by a strong pressure, so the cutting tool edge should be very sharp and the material itself has to bear the relatively large pressure. Therefore the cutting effect for the soft, flexible material is not good, especially more difficult for sticky material.



Advantages:



  • Cutting speeds can be increased substantially
  • The vibration of the ultrasonic food processing system using high frequency wave to quickly cut food;
  • Greatly reduced normal down time for clean up
  • Provides a new way to cut piece, cutting, steering, and transfer alignment or different kinds of food;
  • Makes the cost of production flow minimization;
  • Especially for cutting high viscosity food;
  • Cutting is very hygienic;
  • The cut food looks neat and beautiful;
  • Suitable for automated assembly line, do not have to make a lot of changes to the original line, saving production costs.
