35kHz Gun Type Hand Portable Spot Welder Machine In Automotive Parts

China 35kHz Gun Type Hand Portable Spot Welder Machine In Automotive Parts supplier
35kHz Gun Type Hand Portable Spot Welder Machine In Automotive Parts supplier 35kHz Gun Type Hand Portable Spot Welder Machine In Automotive Parts supplier 35kHz Gun Type Hand Portable Spot Welder Machine In Automotive Parts supplier

Large Image :  35kHz Gun Type Hand Portable Spot Welder Machine In Automotive Parts

Product Details:

Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HSW35

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: Negotiation
Packaging Details: Carton or Wooden Case
Delivery Time: Within 7 weekdays after receipt total amount
Payment Terms: T/T, Western Union
Supply Ability: 2000pcs per month
Contact Now
Detailed Product Description
Item No.: HSW35 Frequency: 35kHz
Power: 1000W Horn: ≤10mm
Housing Diameter: 44mm Color: Bule And Silver
Shipping: TNT UPS DHL FEDEX Warranty: 1 Year



High Power Ultrasonic Spot Welding Machine Portable 35kHz Gun Type Hand Welder in Automotive





Description:



The Ultrasonic Welding Gun we offer can prove helpful for you when it comes to welding thermoplastic items. It is an efficient tool weld the areas that tough and big. This product available on our site in the design of a gun. It has straight staple and small diameter. This makes sure that you can get firm grip on the ultrasonic machine while using it. You don’t have to worry this tool being loose in connections. It has optimum quality connectors in it to counter such possibility. We have made the design of the tool simple, so that you can find it easy to operate it. A variety of models of this machine are also available. This way you can purchase it as per your frequency requirements.
Altrasonic is the market and innovation leader for ultrasonic metal welding.



Ultrasonic welding is a future-oriented process that joins metals together using ultrasound. In addition to copper and aluminum connections, metal and glass can be joined together. In this process, the materials are placed on top of one another and moved against one another under low pressure and high-frequency mechanical vibrations. In just a fraction of a second, a permanent, solid and metallurgically pure joint with outstanding physical properties is created without thermally stressing the components. All this yields a high-quality and economically superior alternative which doesn't require filler materials.





Types of Horn:



35kHz Gun Type Hand Portable Spot Welder Machine In Automotive Parts





Specification:



Item No. HSW20 HSW30 HSW35 HSW40 HSW60
Frequency 20kHz 30kHz 35kHz 40kHz 60kHz
Power 1000W 1200W 1000W 500W 300W-500W
Horn ≤12mm ≤10mm ≤10mm ≤10mm ≤10mm
Housing Diameter 44mm 44mm 44mm 44mm 44mm
Weight of Welder 1.0kg 1.0kg 1.0kg 1.0kg 1.0kg





Application:



Appliance Fixtures, hardware, and enclosure assembly, welding of components.
Automotive Parts and body components, instrument panels, headlight assemblies, under hood assemblies.
Cosmetic Assembly of compacts and other containers, sealing tubes, packaging.
Electronic/Electrical · Component, connector cable and wire harness assemblies, enclosure cases and instrument faces, audio/video cassette and cartridge, switch assemblies.
Food · Sealing of pouches, tray containers and tubes; sealing microwavable containers; product packaging.
Hardware · Product assembly and blister pack packaging.
Health Care · Product containers and accessories.









































35kHz Gun Type Hand Portable Spot Welder Machine In Automotive Parts

35kHz Gun Type Hand Portable Spot Welder Machine In Automotive Parts
