20K Ultrasonic Sealing Machine For Films And Paper Continuous Bonding

China 20K Ultrasonic Sealing Machine For Films And Paper Continuous Bonding supplier
20K Ultrasonic Sealing Machine For Films And Paper Continuous Bonding supplier 20K Ultrasonic Sealing Machine For Films And Paper Continuous Bonding supplier 20K Ultrasonic Sealing Machine For Films And Paper Continuous Bonding supplier

Large Image :  20K Ultrasonic Sealing Machine For Films And Paper Continuous Bonding

Product Details:

Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HSSC20

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: Wooden case
Delivery Time: 15 working days
Payment Terms: T/T, Western Union
Supply Ability: 1000 Set per month
Contact Now
Detailed Product Description
Frequency: 20khz Max. Output Power: 2000 Watt
Application: Sealing And Cutting Frequency Tuning Method: Frequency Tuning Method
Voltage: 110-240V Power Adjusting Method: 30%-99%
Net Weight: 20kg Material Of Horn: Steel
Generator: Analog Automatic Grade: Automatic, Semi-Automatic, Manual
Max. Sewing Speed: 0-20m/min, 20 M/min, Customize, 450spm, 10m/5seconds Max Sewing Thickness: Product Size, 0-6CM, 50MM, 0-2 Mm, 2CM



Ultrasonic Welding Machine 20K 2000W For Composite Materials, Films and Paper Continuous Bonding

Description:


 Ultrasonic non-woven welding machine is an efficient sewing and embossing equipment. It is mainly used for seaming, welding, fusion cutting and embossing of synthetic fiber fabrics. The processed products have good water tightness, high production efficiency, no need for needle thread accessories, smooth cut surface without burr and good hand feeling. Widely used in clothing, toys, food, environmentally friendly non-woven bags, masks and other industries.



Specification:



Frequency

20Khz

Power

2000 watt

Voltage

AC110-240V, 50/60Hz

Power Control

stepping or continuous

Material of welding head

aluminum alloy, stainless steel, titanium alloy, alloy steel.

Weight

4 kg- 20KG

Generator

Analog

Cooling device

compressed air mouth can be installed.

Cable length

3M or customized

Max. sewing speed

0-20m/min, 20 M/min, Customize, 450spm, 10m/5seconds




Competitive Advantage:

1. Ultrasonic welding eliminates the need for needle threading, eliminating the need for frequent needle changing. Without the traditional broken wire joints, it can also clean and partially cut and seal textiles.
2, The stitching also plays the role of decoration, strong adhesion, can achieve waterproof effect, clear embossing, the surface has a three-dimensional relief effect, work speed, product effect is more high-end aesthetic, quality is guaranteed.
3, Using ultrasonic and special steel wheel processing, the edge of the seal does not crack, does not hurt the edge of the cloth, and there is no flashing, curling phenomenon.
4. It does not need to be preheated during manufacturing and can be operated continuously.
5, The operation is simple, and the traditional sewing machine operation method is not much different, ordinary sewing workers can operate
6, Low cost, 5 to 6 times faster than traditional machines, high efficiency.


Applications:

Chemical synthetic fiber fabrics, or chemical fiber blended fabrics, chemical films are also containing more than 30% of the weaving, can be processed into the desired products, such as Nylon cloth, knitted fabrics, non-woven fabrics, T / R cloth, Tedron Cloth (Polyester cloth), glitter cloth, multi-layer cloth, and various laminated coated paper-coated film papers are applicable.




Why Altrasonic?



G   After-sale service:


1.   1. 24 hours techician hotline

2.   2. Preventative maintenance and servicing measures.

      3. Reworking of tooling and spart parts management.

      4. Targeted production process optimization.



     Start up:



1    1. On-site intergration and start-up of the ultrasonic welding syetems by our service specialists.

      2. Ensuring a smooth and fast production start up.

      3. Fine-tuning and optimization of the bonding processing quality.
