CE Ultrasonic Sealing Equipment For PP Non Woven Bags Continuously Sealing

China CE Ultrasonic Sealing Equipment For PP Non Woven Bags Continuously Sealing supplier
CE Ultrasonic Sealing Equipment For PP Non Woven Bags Continuously Sealing supplier CE Ultrasonic Sealing Equipment For PP Non Woven Bags Continuously Sealing supplier CE Ultrasonic Sealing Equipment For PP Non Woven Bags Continuously Sealing supplier

Large Image :  CE Ultrasonic Sealing Equipment For PP Non Woven Bags Continuously Sealing

Product Details:

Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HSSC20

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: Wooden case
Delivery Time: 15 working days
Payment Terms: T/T, Western Union
Supply Ability: 1000 Set per month
Contact Now
Detailed Product Description
Frequency: 20khz Max. Output Power: 2000 Watt
Application: Sealing And Cutting Frequency Tuning Method: Frequency Tuning Method
Voltage: 110-240V Power Adjusting Method: 30%-99%
Net Weight: 20kg Material Of Horn: Steel
Generator: Analog Automatic Grade: Automatic, Semi-Automatic, Manual
Max. Sewing Speed: 0-20m/min, 20 M/min, Customize, 450spm, 10m/5seconds Max Sewing Thickness: Product Size, 0-6CM, 50MM, 0-2 Mm, 2CM



CE Ultrasonic Sealing Equipment For PP Non Woven Bags Continuously Sealing

Description:
Ultrasonic non-woven welding machine is an efficient sewing and embossing equipment. It is mainly used for seaming, welding, fusion cutting and embossing of synthetic fiber fabrics. The processed products have good water tightness, high production efficiency, no need for needle thread accessories, smooth cut surface without burr and good hand feeling. Widely used in clothing, toys, food, environmentally friendly non-woven bags, masks and other industries.
Specification:

Frequency

20Khz

Power

2000 watt

Voltage

AC110-240V, 50/60Hz

Power Control

stepping or continuous

Material of welding head

aluminum alloy, stainless steel, titanium alloy, alloy steel.

Weight

4 kg- 20KG

Generator

Analog

Cooling device

compressed air mouth can be installed.

Cable length

3M or customized

Max. sewing speed

0-20m/min, 20 M/min, Customize, 450spm, 10m/5seconds



Competitive Advantage:

1. Ultrasonic welding eliminates the need for needle threading, eliminating the need for frequent needle changing. Without the traditional broken wire joints, it can also clean and partially cut and seal textiles.
2, the stitching also plays the role of decoration, strong adhesion, can achieve waterproof effect, clear embossing, the surface has a three-dimensional relief effect, work speed, product effect is more high-end aesthetic, quality is guaranteed.
3, using ultrasonic and special steel wheel processing, the edge of the seal does not crack, does not hurt the edge of the cloth, and there is no flashing, curling phenomenon.
4. It does not need to be preheated during manufacturing and can be operated continuously.
5, the operation is simple, and the traditional sewing machine operation method is not much different, ordinary sewing workers can operate
6, low cost, 5 to 6 times faster than traditional machines, high efficiency.

Applications:

Lace clothing, lace underwear, packaging ribbons, shoe flowers, shoe covers, bedspreads, gloves, duvet covers, pillow cases, bed covers, bills, raincoats, umbrellas, tablecloths, mouth cloths, chopsticks sets, car covers, duvet covers, coasters, Curtains, handkerchiefs, bags, non-woven bags, non-woven products, filter bags, tea bags, soft gauze screens, chestless underwear, pajamas robe, head hair accessories, packaging ribbons, bunting ribbons, Craft jewelry, lampshade, textile shoe cover, disposable surgical coat, mask, surgical bag, packaging bag, shopping bag, gift bag, information bag, file bag, advertising bag, dust cover, filter material, speaker soundproof felt, shockproof Lining, garment lining, carpet, cushion lining, car roof, door lining, car filter, vacuum cleaner filter bag, curtains, crafts, etc.

Why Altrasonic?

G   Great customer service :
1.   1. Our sales team is composed with market specialists, with specific knowledge of various business sectors, to ensure the most appropriate

      answer to each customers' specific need : Quotation, Sales administration, Order follow-up, Logistics, ...
2.   2.  Our after-sales department is dedicated to Customer Services :

      Start up and commissioning of equipment worldwide. Our engineers ensure start-up for an optimum production of our equipment

3.   3. Training of customer’s operators. Our service proposes training of your operators to optimize your Decoup+’s device use and increase              your productivity.

      4. Spare-parts, repairs and equipment performances evaluation to maintain and keep your investment up-to-date
