Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines

Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines
Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines

Large Image :  Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines

Product Details:
Place of Origin: China
Brand Name: Altrasonic
Certification: CE
Model Number: HS-C30
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $45-$2800
Packaging Details: wooden case
Delivery Time: 10-15days
Payment Terms: Western Union, MoneyGram, T/T, L/C
Supply Ability: 1000sets per month

Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines

Description
High Light:

ultrasonic cutting knife

,

ultrasonic cutting devices

'

 30KHZ Ultrasonic Cutter for Themoplastic Triming Installed on Machine or Lines



Description:

Ultrasonic cutting is a new technology with enormous potential to replace more traditional cutting processes. Ultrasonic cutting has already being implemented in a wide variety of applications all over the world. Ultrasonic cutting differs greatly from other cutting methods. This technology replaces waterjet, laser cutting, hard tooling and manual trimming or routing methods. Whatever your current approach, Altrasonic ultrasonic technology can reduce operating costs and improve trim quality.



Specification:



Model HS-C30
Frequency 30KHZ
Output Power 200W
Generator Digital generator, 452 x 180 x 100mm
Handle Φ44×220
Size of cutter Blade replaceable
Length of cable 3M
Outer skin Aluminum
Weight 8KG
Voltage 220V / 110V
Accessory Foot switch 1pc;
1.5mm special hex wrench 1pc;Screw M3×4L 2pcs
Material of blade titanium alloy, stainless steel



Advantages:



Clean and Precise: Improves cut quality for carpets, headliners, plastics and more, compared to conventional methods

Small Footprint: With its slim design and efficient operation, reducing your operating and retooling costs.

Lean Operation: Designed for maximum flexibility and uptime with self-sharpening tools and fast changeover.



Applications:



Resin plate

Glass fiber (GFRP)

Formed decorative film

Foam

Blow-molded parts

Injection-molded parts

Carbon fiber (CFRP)

Aluminum foil composites

Non-woven fabrics

Controlled-depth kiss cutting



FAQ



1. How can I ensure your ultrasonic cutter sharp enough for my application?



The sharpness of Ultrasonic Cutters differs according to various combinations of oscillator, transducer, and blade. Because of abundant experience, our company prepares combinations suitable for various materials. Since we can select the model most suitable for your cutting work, we ask that you confirm the sharpness of the selected model by test cutting first.



2. Can it be installed on my present lines?

Yes, ultrasonic cutting and processing equipment can be installed easily. Altrasonic equipment can be as simple as removing the conventional knife and replacing it with a plate to which the ultrasonic knives are attached. Another option is replacing the existing cutting/slitting station with a gantry system that straddles the conveyor you now have.

3. Is the equipment reliable?

Altrasonic Ultrasonics technology has been continuously improved over our 10 years in the business. All equipment and tooling designs undergo many months of reliability testing before being approved for industrial grade applications.



Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines 0

Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines 1

Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines 2

Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines 3Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines 4Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines 5Black Ultrasonic Cutting Machine For Themoplastic Triming Installed On Machine Or Lines 6
