Product Details:
|
| Power: | 2000w | Frequency: | 20khz |
|---|---|---|---|
| Generator: | Digital Generator | Input Voltage: | 220V/50HZ |
| Control: | CPU Control,automatic Scanning/tracking | Components: | Digital Generator, Transducer, Booster, Welding Horn |
| Materials Of Horn: | Special Steel | ||
| High Light: | ultrasonic metal welder,ultrasonic metal welding |
||
20K Ultrasonic Metal Welding Machine for Welding Solar Plate
Description:
ultrasonic metal welding machine is the high frequency vibration between the work piece surface, until the contact surface heating and welding together. As copper, silver, nickel chromium canwelding to dot or strip, which can be widely applied to the silicon chip fuses, quick fuse melts melting, electrical wire terminals, lithium ion, nickel metal hydride, nickel cadmium battery pole piece such as dot, strip welding.
Specification:
| Frequency | 20 Khz |
| Output Power | 2000 W |
| Voltage | 220 V |
| Switch | Handle or foot switch |
| Power Adjusting | Step or continuous |
| Working Time Control | 24 Hours |
| Weignt | 20-30 KG ( Determined by the size of the horn ) |
| Generator | Digital Generator |
| Welding speed | 10m / s |
Principle:
By using the ultrasonic high frequeccy vibration principle, the ultrasonic metal welder converts the ultrasonic vibration energy into friction energy to transfer the metal’s surface. Under condition of producing the heat by the friction and putting apressure to the metal, The metal pieces will fuse.
Advantage:
Fast - the welding time is adjustable from 1 to 3 seconds.
Strength - can withstand enough tension, strength adjustable.
Quality - excellent welding effect, no burning, no blackening.
Economy - no glue, less labor, less cost.
Application:
welding solar plate, welding thin metal material, and other rotary welding application.
20K Ultrasonic Metal Welding Machine for Welding Solar Plate
FAQ:
1.What is the difference between Ultrasonic metal welding machine and ultrasonic plastic welding machine ?
The vibration direction of the welding head in the ultrasonic plastic welding is perpendicular to the welding position. In the ultrasonic metal welding machine, the vibration direction of the welding head is parallel to the welding position.
2.How do you control production quality ?
3 times old test to confirm the products is well quality.
20 technician work together , and learn together , to improve our products.
48 hours working time to test the stability of our product before sending out.
3.Can customized, modify,develop products according to the drawing?
A:Yes, we provide OEM service, we can customized products according to the drawings?
