70khz Ultrasonic Plastic Welding Machine / RFID Inlays Device for Contactless Card

China 70khz Ultrasonic Plastic Welding Machine / RFID Inlays Device for Contactless Card supplier
70khz Ultrasonic Plastic Welding Machine / RFID Inlays Device for Contactless Card supplier 70khz Ultrasonic Plastic Welding Machine / RFID Inlays Device for Contactless Card supplier 70khz Ultrasonic Plastic Welding Machine / RFID Inlays Device for Contactless Card supplier 70khz Ultrasonic Plastic Welding Machine / RFID Inlays Device for Contactless Card supplier

Large Image :  70khz Ultrasonic Plastic Welding Machine / RFID Inlays Device for Contactless Card

Product Details:

Place of Origin: CHINA
Brand Name: Altrasonic
Certification: CE
Model Number: HSD70S

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: Wooden case
Delivery Time: 7 working days
Payment Terms: T/T, Western Union
Supply Ability: 5000 Set per month
Contact Now
Detailed Product Description
Frequency: 70khz Power: 300w
Power Adjusting Method: Step Or Continuous Switch: Handle,foot Switch.or Linked Outside
Working Time Control: 0-999seconds Generator: Digital Generator
Net Weight: 10kgs The Threading Hole: Ø0.5m Or Design According To Customers' Need
Cooling Down Method: Compressed Air Outer Housing: Aluminium Or Nylon

70khz Ultrasonic RFID Inlays Device with High Quality for Contactless Card



Principle of 70 Khz Card Implanting Welder :



High Speed wire embedding with multiple embedding heads. Using the latest in linear servo technology and ultrasonic embedding units coupled together with vision cameras the wire embedding system is unrivalled in its speed, accuracy and the quality of antennae that it produces. Capable of working with a range of materials and wire diameters and an easy to use interface making solid wire antennas was never so easy.



Parameters:



Frequency 70khz
Power 500w
Power Adjusting Step or continuous
Switch Handle , foot switch,or linked outside
Working Time control 0-999seconds
Generator Digital generator
Cable 2M, national standard
The threading hole Ø0.5m or design according to customers' need
Cooling down method Compressed air
Outer housing aluminium or nylon



Specifications:



Components and Parts Ultrasonic digital generator
Booster
Converter
Embedding / welding horn
Protective Sleeve (Nylon and Aluminum optional)
HF Cable
Power cord



Benefits:



1.steady welding point, completely eradicate insufficient solder technically.

2.the size of welding spots is the same, equality line, good effect on uniformity

3.the welding spot is small, wouldn’t increase the weight of the coil, easy to do lamination and encapsulation

4.to leave out the immersion tin step before doing welding ,save an operator.

5. after skilled in welding, much faster than the way to use searing iron to do weld.

6.on the process on manufacturer, there is no waste gas, waste rubbish on pollution, runs in quiet and no noise.

7.to select the the frequency 60KHz, one machine could drive 5-10 ultrasonic products, the speed to do welding is much faster.

8.low power consumption, to save production cost for manufacturer enterprise.



Difference between ultrasonic embedding technology and traditional winding technology



Traditional winding process of production steps: coil, rationale coils, cut immersion thread, artificial welding coil to the COB, bonding the welded coil to the sheet a total of five processes, only winding is semi-automated or automated equipment to complete, The other four processes are completed by hand. Productivity underground, production costs more expensive. Especially welding COB process, manual welding efficiency is only about 600PCS / H, and often accompanied by Weld, false welding and other undesirable phenomena. In addition, due to more manual processes, the uniformity of product performance is poor.



The process of ultrasonic embedding process: pick up chip + chip to sheet metal, embedded wire + shear line + touch welding to complete, a total of two processes, complete automation equipment complete.High production efficiency, lower production costs, and the entire process is completed by the equipment, the performance is more consistent.



With the increase of labor costs in China, more and more manufacturers are aware of the importance of automation equipment, which makes the application of automation equipment more and more high.At the same time, users, purchasers, supply chains, agents and other products have higher and stricter requirements on the performance of the products.



70khz Ultrasonic RFID Inlays Device with High Quality for Contactless Card



70khz Ultrasonic Plastic Welding Machine / RFID Inlays Device for Contactless Card



70khz Ultrasonic Plastic Welding Machine / RFID Inlays Device for Contactless Card
